CHIEFTEC PSU Stealth (1200W), >92%, 80+ Platinum, 135mm FDB, 1xMB 24pin(20+4), 2xCPU 8pin(4+4), 2xMolex, 10xSATA, 3xPCIe 8pin(6+2), 2xPCIe GEN5 16pin, Fully Modular

Model :Stealth 1200W
Article no. :SPX-1200-FC
EAN code :0753263079268
Weight (without/with package) :2.86kg / 3.79kg
AC Input :100 - 240V~ / 15.0 - 7.5A
Frequency :50 - 60Hz
+5V :20A
+3,3V :20A
+5V & +3,3V combined :100W
+12V1 :100A
+12V2 :-
+12V1, +12V2 combined :1200W
P.F. :≥0.95
-12V :-
+5VSB :3.0A / 15W
Maximum Power :1200W

Connectors
20+4 PIN ATX :1
8 PIN EPS :1
8 PIN EPS (4+4) :1
8 PIN PCIe (6+2) :3
16 PIN 12V - 2 x 6 :2
SATA :10
MOLEX :2

Cable length (mm)
20+4 PIN ATX :600
8 PIN EPS :700
8 PIN EPS (4+4) :700
8 PIN PCIe (6+2) :3 x 650
16 PIN 12V - 2 x 6 :2 x 650
SATA :2 x 500/150/150/150
SATA/MOLEX :500/150/150/150


Features
ATX12V Version :ATX 12V 3.1
Efficiency :80Plus Platinum
Dimension (DxWxH) :140mm x 150mm x 86mm
PFC :Active PFC
Fan :135mm FDB fan
Security :AFC (Automatic Fan Speed Control)
OPP (Overload Protection)
OTP (Over Temperature Protection)
OVP (Overvoltage Protection)
SCP (Short-Circuit Protection)
SIP (Surge & Inrush Protection)
UVP (Under Voltage Protection)
OCP (Over-Current Protection)
